The MV269 is Morion’s new miniature, high frequency, low phase noise oven controlled crystal oscillator (OCXO). It is available 60-120 MHz, offers a phase noise floor below -170 dBc/Hz and is housed in a 21.0 x 13.0 x 9.5 mm package.Temperature stability up to ±5.0×10-8 and aging of ±1.0×10-7 /year is available.
Applications include PLOs and synthesizers.
